Morguen Micro Tools (MMT)

Our Special Dental-MMT this month:





We are your specialists in Micro Cutting Tools manufacturing for different



DENTAL Applications



"Made in Germany"



CLICK FOR WEBSITE

Application for DENTAL MicroCuttingTools

Type

d1

(mm)

l1

(mm)

d2

(mm)

z Application Coating Description



RDC 210



0,5 - 4,0



35 - 60



3 / 4 / 6



2



Zirconium



Diamond



Ball nose router



RDC 450



2,0 - 4,0



35 - 60



3 / 4 / 6



4



Zirconium



Diamond



Router with corner radius



RNR 200



1,0   1,5



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Router with flat end cut



RNR 210



0,5 - 4,0



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Ball nose router



RNR 250



1,0 - 3,0



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Router with corner radius



RNR 260



0,3   1,5



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Ball nose router



RNR 280



1,0   3,0



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Ball nose router



RVR 200



0,5   3,0



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Router with flat end cut



RVR 210



0,5 - 4,0



35 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Ball nose router



RVR 260



0,6



29 - 60



3 / 4 / 6



2



CoCr, Titanium



PVD



Conical ball nose router



RVR 400



1,5



29 - 60



3 / 4 / 6



4



CoCr, Titanium



PVD



Cylindrical router with flat end cut



RZC 210



0,5 - 4,0



29 - 60



3 / 4 / 6



2



Zirconium



None



Ball nose router



RZC 250



1,0 - 3,0



29 - 60



3 / 4 / 6



2



Zirconium



None



Cylindrical router with corner radius



RZC 260



0,3   1,5



29 - 60



3 / 4 / 6



2



Zirconium



None



Conical ball nose router



RZC 400



0,5   2,4



35 - 60



3 / 4 / 6



4



Zirconium



None



Cylindrical router with flat end cut



RZC 450



2,0 - 4,0



35 - 60



3 / 4 / 6



4



Zirconium



None



Router with corner radius



RZL 110



1,0   3,0



35 - 60



3 / 4 / 6



1



PMMA



None



1-flute router with ball nose



RZL 210



0,5 - 4,0



29 - 60



3 / 4 / 6



2



PMMA



None



Ball nose router



XCC 010



1,0   3,0



35 - 60



3 / 4 / 6



0



Lithium disilicate



Diamond



Grinding pin, ball nose, cylindrical



XCC 060



0,6



35 - 60



3 / 4 / 6



0



Lithium disilicate



Diamond



Grinding pin, ball nose, conical



Zirconium Router          RZC 210

MMT for routing pre-sintered high-performance ceramics such as zirconium oxide and aluminium oxide.



Our ball nose routers, made of solid carbide, are 100% checked.

This tool has a straight shank (DIN 6535 HA).

Zirconium Router          RDC 210

MMT for routing pre-sintered high-performance ceramics such as zirconium oxide and aluminium oxide.



Our diamond coated ball nose routers, made of solid carbide, are 100% checked.

This tool has a straight shank (DIN 6535 HA).



Our coating gives the tool a significant higher life time compared to uncoated tools.

CoCr Router          RNR 210 / RVR 210

MMT for routing CoCr steels, titanium or titanium alloys.



Our coated ball nose routers, made of solid carbide, are 100% checked.

This tool has a straight shank (DIN 6535 HA).



The tool with the PVD coating shows an extraordinary good performance.

Plastics Router      RZL 210

MMT for routing plastics such as PMMA and wax.



Our ball nose routers, made of solid carbide, are 100% checked.



This tool has a very high productivity as the geometry has especially been developed for these applications.

Our additional offer of Service







MMT provides distance rings according to customer specification



  • Distance rings made of plastic for shank diameter 3 mm
  • Snap rings made of spring steel for shank diameter 3 mm
  • Distance rings made of brass for shank diameter 3 mm
  • On request we offer for our 6 mm shank tools a weldon cut (clamping surface) acc. to DIN 1835 B

Solid Carbide

  • Benefit from our long time experience in the production of carbide tools!
  • We have the right type of carbide for your application.
  • For the production of our tools we use only finest grain carbide and ultra fine grain carbide.



Coatings

  • Our coatings are adapted to the respective applications.
  • Due to continous development of our coatings w can ensure the maximum customers benefit.
  • You can achieve a considerable increase of performance with our coated tools.



Development

  • Our tools are developed at the factory in our modern Technology Center in Germany!



Quality and Environment

  • Our quality and Environmental Management System has been certified acc. DIN EN ISO 9001 and 14001.



Company

  • Our production is located in Germany!
DOWNLOAD NEW DENTAL Catalogue DE-EN
2016 NEW DENTAL Catalogue DE-EN.pdf
PDF-Dokument [7.1 MB]
